New / Modified Tool Suggestions Section?

  • New / Modified Tool Suggestions Section?

    Posted by Vince French on August 4, 2021 at 12:34 am

    I haven’t seen this anywhere else @troydegroot so hope I haven’t missed something!

    Just wondering if it is worth having a section in this group for new tool / modifications suggestions from members?

    It would be interesting to see whether members have similar problems / issues using the package and if there are any simple modifications that could be put forward to Bluebeam? I am aware you can put forward suggestions individually but a discussion on here might reveal common issues, solutions already available, etc..

    If so, I would like to kick this off by suggesting that the boundary tool in Dynamic Fill is updated so it can be much finer. Although this currently works well when you are applying a boundary to a straight edge it becomes rather more difficult to accurately apply to an irregular shape.

    What do you think?

    Vince French replied 2 years, 7 months ago 3 Members · 8 Replies
  • 8 Replies
  • David Cutler

    Member
    August 4, 2021 at 7:08 am
    Points: 23,145
    Rank: UC2 Brainery Brown Belt III UC2 Brainery Brown Belt III

    It would also be helpful if there was a setting that allowed markups to serve as boundaries for dynamic fill.

  • Troy DeGroot

    Organizer
    August 4, 2021 at 4:41 pm
    Points: 20,776
    Rank: UC2 Brainery Brown Belt UC2 Brainery Advanced Brown Belt Rank

    I also ran into this yesterday, the Boundary size I can work with most time because you just have to line up one side of the thick line, it doesn’t have to be associated with anything at all. I was running into an issue where the Fill dot was too big. In full disclosure, I was creating tiny social media buttons for my email signature. 😂

    • Vince French

      Member
      August 5, 2021 at 12:10 am
      Points: 11,788
      Rank: UC2 Brainery Blue Belt I UC2 Brainery Blue Belt I

      I’ve run into the problem of the dot being too big as well e.g. areas like shingle margins around a house.

      With the boundary, a lot of the time I find it difficult to get the thick line neatly / accurately lined up with irregular shapes – whether this is curved areas or maybe even trying to stop the fill half way through a door opening in a wall. It may not make too much difference to the overall area measurement but it bugs the hell out of me because it just doesn’t look right! 😆

      • David Cutler

        Member
        August 5, 2021 at 6:53 am
        Points: 23,145
        Rank: UC2 Brainery Brown Belt III UC2 Brainery Brown Belt III

        At times I get frustrated with the dynamic fill results when the limits of the markup aren’t “smooth” for lack of a better term. I find that I end up going back in and deleting “extra” points to make the markup “look right” as you say Vince. Many times this appears to be an issue with the quality of the original linework. While I like the concept of dynamic fill sometimes I find it quicker to just click my way around a shape rather than going back to clean up the “extra” control points.

        • Troy DeGroot

          Organizer
          August 5, 2021 at 10:55 am
          Points: 20,776
          Rank: UC2 Brainery Brown Belt UC2 Brainery Advanced Brown Belt Rank

          You might try adjusting the Edge Sensitivity in the Dynamic Fill Properties..

          • Vince French

            Member
            August 5, 2021 at 1:30 pm
            Points: 11,788
            Rank: UC2 Brainery Blue Belt I UC2 Brainery Blue Belt I

            I have adjusted everything as much as possible but could still do with being able to adjust even more – just being fussy I guess! 😆

    • David Cutler

      Member
      August 5, 2021 at 6:55 am
      Points: 23,145
      Rank: UC2 Brainery Brown Belt III UC2 Brainery Brown Belt III

      You really should have your IT staff putting those things together for you Troy so you can focus on more important task. 🙂

      • Troy DeGroot

        Organizer
        August 5, 2021 at 10:59 am
        Points: 20,776
        Rank: UC2 Brainery Brown Belt UC2 Brainery Advanced Brown Belt Rank

        My IT guy sent me to my marketing guy, who sent me to my graphics designer. After getting the run-around, I just decided to do it myself! 😂
