Mitch Youngs

Member

January 6, 2023 at 9:22 pm in reply to: Visual Basic coding, Cells to Form Fields export

Points: 313

Rank: UC2 Brainery Newbie

Isaac or anyone else trying to figure out the VBA code feel free to ask questions.

One thing I did want to mention is that this specific code has logic to figure out if it is a Bid Item (100) or sub item (100.01) so it needs to create a new sheet because it has run out of available rows. Also, I tend to use tables in excel so I can reference data by column name instead of hard coding.

I have a simpler form with only adding a few cells of data and not much logic in it if you want me to share that one.

Mitch Youngs

Member

January 6, 2023 at 3:44 pm in reply to: Visual Basic coding, Cells to Form Fields export

Points: 313

Rank: UC2 Brainery Newbie

Try this out. I made it work with just the template file and macro-enabled excel. Tip there is javascript on formatting my fields for template so after you open the fdf hold down the tab key and it will reformat the text in each cell.

Copy Download Link

Mitch Youngs

Member

January 5, 2023 at 6:31 pm in reply to: Visual Basic coding, Cells to Form Fields export

Points: 313

Rank: UC2 Brainery Newbie

I have a few questions on what you want to do.

Are the form fields the same every time you see the Pdf?

Are you creating the form/forms initially or is there information you need to preserve in form fields?

If the flow just from Excel -> Bluebeam or do you need to pull information from the form later?

Mitch Youngs

Member

January 6, 2023 at 2:00 pm in reply to: Visual Basic coding, Cells to Form Fields export

Points: 313

Rank: UC2 Brainery Newbie

Honestly I run all of my macros from an add in I made so none of my excel documents are macro-enabled. I’m trying to make work in a zip folder to upload here so that you can open and run it without changing a bunch of code. For now here is the code that i think has all of what you would need to reference and the template pdf but i’ll upload something better in a bit.

Copy Download Link

Copy Download Link

Public Sub MakeFDF()

    Dim TurnOn As Boolean
    If Application.ScreenUpdating = True Then 'Turn off screen updating to make it faster
        Call Update_off
        TurnOn = True
    Else: TurnOn = False
    End If


    Dim sFileHeader As String
    Dim sFileFooter As String
    Dim sFileFields, sFileFieldItem, sFileFieldMaterial, sFileFieldProduct, sFileFieldManufacture, sFileFieldRAM, sFileFieldRamCode As String
    Dim sFileName As String
    Dim sTmp As String
    Dim lngFileNum As Long
    Dim lrow As ListRow
    Dim BidNum, Qty, Unit, BidItem, Product, Manufacturer, Acceptance, RamNo, AppCode, PayItem As String
    Dim FNRSavePath, FNRSaveFile, PDFTemplateFile, fdfName As String
    Dim ItemRow, lastrow, LastRow2 As Long

     'Define where data you are going to use to fill out PDF forms
    Dim Contract_No, Project_Name, Project_No As String
    Contract_No = Worksheets("Rom").Range("L5").Value
    Project_Name = Worksheets("Rom").Range("G5").Value
    Project_No = Worksheets("Rom").Range("L6").Value

    Dim tblRom As ListObject		'I used a Table for most of my data
    Set tblRom = Worksheets("Rom").ListObjects("ROM")
    lastrow = tblRom.DataBodyRange.Rows.Count       'Last Row
    'LastRow2 = Worksheets("Rom").Range("A9999").End(xlUp).Row  'Last Row without referencing table

    PDFTemplateFile = "P:\Public Works\01 Administration\FORMS\04 Construction\08 Inspection Docs\Field Note Record-Grid 4-22.pdf" 'Template File Name and location
'setting default save path for pdfs and check if folder exist with browsing for location as a pop up if location does not work
    FNRSavePath = ThisWorkbook.Path
    ChDrive "P"
    ChDir FNRSavePath
    ChDir ".."
    FNRSavePath = CurDir
    ChDir ".."
    FNRSavePath = CurDir
    FNRSavePath = FNRSavePath & "\05 Inspector Documents\02 Field Note Records\DATA"

FNRSavePath = CheckFolderExists(FNRSavePath, " Inspector Documents FNR DATA ") ' this will be what shows in pop up to browse for a folder location

    If FNRSavePath = "" Then
        Exit Sub
        End If

'setting up counters to deal with looping through
    Dim counter, counter2, endnumber, iFields, pagecount, i As Integer
    endnumber = 9
    counter = 1
    counter2 = 1
    iFields = 1
    pagecount = 0

For Each lrow In tblRom.ListRows

BidNum = Intersect(lrow.Range, tblRom.ListColumns("Bid Item").Range).Value
    Qty = Intersect(lrow.Range, tblRom.ListColumns("Item Qty.").Range).Value
    Unit = Intersect(lrow.Range, tblRom.ListColumns("Unit").Range).Value
    BidItem = Intersect(lrow.Range, tblRom.ListColumns("Material").Range).Value
    Product = Intersect(lrow.Range, tblRom.ListColumns("Product").Range).Value
    Manufacturer = Intersect(lrow.Range, tblRom.ListColumns("Manufacturer").Range).Value
    Acceptance = Intersect(lrow.Range, tblRom.ListColumns("Acceptance").Range).Value
    'Spec = Intersect(lrow.Range, tblRom.ListColumns("Specification Section").Range).Value ' not needed column
    RamNo = Intersect(lrow.Range, tblRom.ListColumns("RAM No.").Range).Value
    AppCode = Intersect(lrow.Range, tblRom.ListColumns("RAM/QPL Approval Code").Range).Value

    If Intersect(lrow.Range, tblRom.ListColumns("Bid Item").Range).Interior.Color = RGB(214, 133, 255) Then GoTo Line7 'skipping items that are not used
    If Intersect(lrow.Range, tblRom.ListColumns("Bid Item").Range).Interior.Color = RGB(255, 117, 117) Then GoTo Line7 'skipping items that are rejected
Line5A:
If counter  1 Then GoTo Line8
    PayItem = BidNum
    FNRSaveFile = FNRSavePath & "\" & PayItem & ".pdf"
    If (Dir(FNRSaveFile)  "") Then
        Kill FNRSaveFile
    End If
    Call FileCopy(PDFTemplateFile, FNRSaveFile) 'Copy Template
    fdfName = PayItem & ".pdf"

    sFileHeader = "%FDF-1.2" & vbCrLf & _
                  "%âãÏÓ" & vbCrLf & _
                  "1 0 obj<</FDF<>>>" & vbCrLf & _
                  "endobj" & vbCrLf & _
                  "2 0 obj[" & vbCrLf

sFileFooter = "]" & vbCrLf & _
                  "endobj" & vbCrLf & _
                  "trailer" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "%%EO"

sFileFields = "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf
     sFileFields = sFileFields & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf

    sFileFields = sFileFields & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf & _
                  "<>" & vbCrLf

'"<>" & vbCrLf

'Static on Sheet
        sFileFields = Replace(sFileFields, "---Contract_No---", Contract_No)
        sFileFields = Replace(sFileFields, "---Project_Name---", Project_Name)
        sFileFields = Replace(sFileFields, "---Project_No---", Project_No)

If Len(Acceptance) = 0 Then GoTo Line3 Else GoTo Line4

Line8:

For i = 1 To 8
    sFileFields = Replace(sFileFields, "---Item" & i & "---", "")
    sFileFields = Replace(sFileFields, "---Material" & i & "---", "")
    sFileFields = Replace(sFileFields, "---Product" & i & "---", "")
    sFileFields = Replace(sFileFields, "---Manufacturer" & i & "---", "")
    sFileFields = Replace(sFileFields, "---RAM" & i & "---", "")
    sFileFields = Replace(sFileFields, "---RamCode" & i & "---", "")
    'sFileFields = Replace(sFileFields, "---Acceptance" & i & "---", "")
    Next i

'Save the item by the bid number
    sTmp = sFileHeader & sFileFields & sFileFooter
    sFileName = FNRSavePath & "\_" & PayItem & ".fdf"
    If (Dir(sFileName)  "") Then
        Kill sFileName
    End If
    lngFileNum = FreeFile
    Open sFileName For Output As lngFileNum
    Print #lngFileNum, sTmp
    Close #lngFileNum
    DoEvents


    counter = 1
    counter2 = 1
    iFields = 1
    pagecount = 0
    GoTo line1

line2:

    If Len(BidNum) > 6 Then BidNum = Int(BidNum)
    sFileFields = Replace(sFileFields, "---Item" & iFields & "---", BidNum)
    sFileFields = Replace(sFileFields, "---Material" & iFields & "---", BidItem)
    sFileFields = Replace(sFileFields, "---Product" & iFi...

Expand

This file was truncated for preview. Please download to view the full file.

Mitch Youngs

Member

January 6, 2023 at 1:18 pm in reply to: Visual Basic coding, Cells to Form Fields export

Points: 313

Rank: UC2 Brainery Newbie

I got it to upload.

Mitch Youngs

Member

January 5, 2023 at 7:05 pm in reply to: Visual Basic coding, Cells to Form Fields export

Points: 313

Rank: UC2 Brainery Newbie

Here is a screen recording of what my code does and my workflow if that helps.

Copy Download Link

Mitch Youngs

Member

January 5, 2023 at 6:48 pm in reply to: Visual Basic coding, Cells to Form Fields export

Points: 313

Rank: UC2 Brainery Newbie

I’m just trying to figure out what code to send to you that would be most helpful.

Mitch Youngs

Member

January 5, 2023 at 6:44 pm in reply to: Visual Basic coding, Cells to Form Fields export

Points: 313

Rank: UC2 Brainery Newbie

Do you need to create multiples of this form at one time?

The way mine is set up i generate multiple pdf’s (about 150ish) from a template and rename them with vba then create all of the fdf files with vba that match the pdf’s.
